ITEM PART NO. QTY. DESCRIPTION
1 A13084 1 Barrell (Non-Stock Item)
2 GD27237 1 Nylon Lock Nut, 1¼"-12, Grade 8
3 *D12148 1 Wear Ring
4 *D12282 1 T-Seal
5 GD14910 1 Piston
6 *D12223 1 O-Ring
7 GD18524 1 Cylinder Rod
8 *D12242 1 O-Ring, No. 345
9 *D12243 1 Back-Up O-Ring, No. 348
10 *D12255 1 U-Cup
11 GD12522 1 Gland
12 *D12240 1 Wiper, 2"
13 GD12106 1 Ring
14 G11081 1 Hex Jam Nut, 1½"-12, Grade 2
15 GA13998 1 Clevis
16 *D12239 1 O-Ring, No. 016
17 G6408-08
GR1037 4
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
18 GD11579 1 Block
19 G10932 2 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
20 G6801-LL-06-08 1 X-Long Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To ¾"-16 O-Ring
21 GA8882
GR1517 1
-
Counter Balance Valve
Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
22 GA13191 1 Steel Hydraulic Line
23 G6801-06-08
GR1037 1
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To ¾"-16 O-Ring
O-Ring
A GA13094 - Cylinder Complete, 4½" x 6" (Part Number Stamped On Barrel)
B GR1924 - Seal Kit, Includes: (3) O-Rings, (1) Back-Up Ring, (1) U-Cup, (1) Wiper, (1) T-Seal,
(1) Wear Ring
*Part of seal kit, item can not be purchased individually.
R.H. Wing Lock Up Cylinder
Model 3660 M0217-02
Rev. 6/14 P166
