P154 – Kinze 3660 Lift and Rotate Planter Rev. 6/14 User Manual
Page 157
ITEM
PART NO.
QTY.
DESCRIPTION
1
GA13017
G10640
1
-
Wing Wheel Arm
Grease Fitting, ¼"-28
2
GA2148
GR0434
1
-
Hub W/Cups, 6 Bolt
Cup
3
GA4376
GD11490
1
-
Spindle W/Round External Retaining Ring, 10"
Round External Retaining Ring
4
GA0895
2
Bearing
5
G11081
2
Hex Jam Nut, 1½"-12, Grade 2
6
GA14413
1
Rim, 5.5" x 20"
7
GD13401
1
Tire, 7.50" x 20", 8 Ply, Tubeless W/O Center Rib (Specify Brand*)
8
GR0270
6
Lug Bolt, 9⁄16"-18
9
GD19482
G10026
G10231
G11314
2
4
4
2
Mud Scraper Bracket
Hex Head Cap Screw, ¾"-10 x 2"
Lock Washer, ¾"
Hex Nut, ¾"-10
10
GD19484
G10622
G10305
1
4
4
Mud Scraper
Serrated Flange Nut, ⅜"-16
Carriage Bolt, ⅜"-16 x 1"
11
GA7434
-
Valve Stem
A
GA4377
-
Hub And Spindle Assembly (Items 2, 3, 4, And 5)
B
GA14412
-
Tire And Rim Assembly (Items 6, 7, And 11) (Specify Brand*)
*Specific brand requests will be supplied only as available from current Kinze Repair Parts stock. If a specific brand
requested is not in stock, the brand available will be supplied.
Ground Drive Wheel
Model 3660
M0217-02
Rev. 8/12
P154
TM
