Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 15)

ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 --- - See “Shank Assembly, Seed Tube, and Depth Adjustment” on page P1
2 G10213 - Machine Bushing, ⅝" (.030" Thick)(As Required)
3 GD11259 1 Sleeve, ⅜" I.D. x ⅝" O.D. x 125∕32" Long
4 GA2012R
GA2012L 1
-
Disc Scraper, R.H.
Disc Scraper, L.H. (Shown)
5 G10325
G10622 1
1 Hex Head Cap Screw, ⅜"-16 x 2¾"
Serrated Flange Nut, ⅜"-16
6 G10328
G10622 2
1 Hex Head Cap Screw, ⅜"-16 x ⅝"
Serrated Flange Nut, ⅜"-16
7 GD11845 2 Dust Cap
8 GD11017 1 Special Hex Head Cap Screw, ⅝"-11 x 1½", L.H. Threads
9 G10204 2 Special Machine Bushing, ⅝" x 1" O.D.
10 G10427 12 Rivet, ¼" x ½"
11 GD10473 2 Bearing Housing
12 GA2014 2 Bearing
13 GD11306 2 Disc Blade, 3.5 mm x 15"
14 GB0301 1 Seed Tube Guard/Inner Scraper
15 G10912 2 Hex Socket Head Cap Screw, 5∕16"-18 x 1", Grade 8
A GA8324 - Disc Blade/Bearing Assembly, Less Dust Cap (Items 10-13)
15" Seed Opener Disc Blade/Bearing Assembly and Scrapers
Model 3660 M0217-02
