Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 103)

ASD Tank Assembly (Prior to 2010 Production)
ITEM PART NO. QTY. DESCRIPTION
1 GD19674
G10451 1
2 Lid Hinge Pin
Cotter Pin, ⅛" x 1"
2 GA13780
GD19681-01
GD19681-02
GD19681-03
G10108
G10047 1
6
6
6
4
4 ASD Tank Hinge
Shim, 7 Gauge
Shim, 10 Gauge
Shim, 12 Gauge
Lock Nut, ⅜"-16
Hex Head Cap Screw, ⅜"-16 x 1¾"
3 GA13731
GD19648 1
1 Lid Assembly
ASD Lid Seal
4 GD19677
GD19676-01
GD19676-02
GD19676-03
GD19675
G10451
G10108
G10047 1
3
3
3
2
4
2
2
Latch Catch
Shim, 7 Gauge
Shim, 10 Gauge
Shim, 12 Gauge
Latch Handle Pin
Cotter Pin, ⅛" x 1"
Lock Nut, ⅜"-16
Hex Head Cap Screw, ⅜"-16 x 1¾"
5 GA13792
GD19542
G10451 1
1
2 Latch Handle
Latch Hook
Cotter Pin, ⅛" x 1"
6 GD19419 1 ASD Bulk Seed Tank
7 GA13729 1 Tank Mount
8 GA13788
GD19689
GD19668
G10683
G10107 4
2
2
4
4 Isolator, Univeral Mount
Isolator Backer Strap
ASD Tank Backer Plate
Carriage Bolt, ⅝"-11 x 4½"
Lock Nut, ⅝"-11
9 GD19666
G11166
GD19620
GD19690-01
GD19690-02 1
18
1
1
1
ASD Entrainment Mounting Plate
Flanged Whiz Lock Screw, ¼"-20 x ¾", Serrated
ASD Tank Mount Gasket
Ribbon Sealer, 5'
Ribbon Sealer, 6'
10 GA13915
G10111
G10045 1
1
1 Tank Mount Link
Lock Nut, ½"-13
Hex Head Cap Screw, ½"-13 x 4½"
11 GA13797 2 Front Tank Mount
A GA13701 - ASD Tank Assembly (Items 1-9)
Model 3660 M0217-02
Rev. 7/11 P100
