Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 229)

Conventional Liquid Fertilizer Tanks, Saddle, Saddle Mounts,
and Hoses
ITEM PART NO. QTY.
(Per Tank)
DESCRIPTION
1 GA13632 1 Tank Saddle
2 GA14105
GA16428
GA16157
GR1941
GR1919
GR1709
GR1708 1
1
1
1
2
1
1 Tanks W/Lids And Fittings, 300 Gallon
Lid, 7" W/Vacuum Breaker
Vacuum Breaker
Seal
1½" Bulkhead Fitting Assembly
1¼" Bulkhead Fitting Assembly (Nut, Bushing And O-Ring)
¾" Bulkhead Fitting Assembly (Overflow Fitting, Nut, Bushing And O-Ring)
3 GD15605 2 Band (3 Per Tank)
4 GD11223 2 Anchor (Sub GA8114)
5 G10485
G10901 2
2 Hex Head Tap Bolt, ⅜"-16 x 5"
Lock Nut W/Nylon Insert, ⅜"-16
6 GD19448 1 Bracket
7 G10017
G10228
G10102 4
4
4 Hex Head Cap Screw, ½"-13 x 1½"
Lock Washer, ½"
Hex Nut, ½"-13
8 GA13624 1 Inner Fertilizer Leg
9 GD18954
G10230
G10104 2
7
7 U-Bolt, ⅝" x 6" x 6"
Lock Washer, ⅝"
Hex Nut, ⅝"-11
10 GA13626 1 Front Outer Fertilizer Leg
11 GA13625 1 Rear Outer Fertilizer Leg
12 G10008
G11391 3
3 Hex Head Cap Screw, ⅝"-11 x 2"
Flat Washer, ⅝" SAE
13 G4602-01 1 Black Helix Hose, 1¼" x 18'
14 GA14134 - Hose Holder
Model 3660 M0217-02
Rev. 6/13 P226
