ITEM PART NO. QTY. DESCRIPTION
19 GA6699
GR1956
GR1957
GR1958
GR1208
G11330
G10110 1
-
-
-
-
4
4
Double Light Assembly
Amber Lens Kit, Includes: (1) Amber Lens, (1) Gasket, and (3) Hex Head Cap Screws
Red Lens Kit, Includes: (1) Red Lens, (1) Gasket, and (3) Hex Head Cap Screws
Black Cover Kit, Includes: (1) Black Cover, (1) Gasket, and (3) Hex Head Cap Screws
Bulb
Hex Head Cap Screw, ¼"-20 x 1¼"
Lock Nut, ¼"-20, Grade B
20 GD19587
G11329
G10110
G10308
G11091 2
5
5
12
12
Hose Rack
Hex Head Cap Screw, ¼"-20 x 6½"
Locknut, ¼-20, Grade B
Carriage Bolt, ⅜"-16 x ¾"
Serrated Flange Nut, ⅜"-16
21 GD19586
G11109
G10071 4
8
8 Hose Rack Bracket
Hex Head Cap Screw, ½"-13 x 7½"
Serrated Flange Nut, ½"-13
22 GD19755 4 Hose Tray Mount Plate
23 GD19588 1 Attach Plate
24 G11147
GD2117 -
- Cap, 2"
Cable Tie, 14½"
Wing Frame, 16 Row
