ASD Tank Assembly (2013 Production and on)
ITEM PART NO. QTY. DESCRIPTION
1 GB0673
GD24879-01 1
-
ASD Tank Lid
Rope Tether, 36”
2 GB0674 1 ASD Tank Latch Ring
3 GD24385-01 1 Ribbon Sealer, 66½"
4 GB0675 1 ASD Tank Lid Seal
5 GD24386 6 ASD Lid Seal Ring Segment
6 G11522 18 Phillip Pan Head Tapping Screw, #8-18 x ⅝"
7 GD24753
GD24754 4
4 Hex Socket Head Machine Screw, ¼"-20 x 1½", Grade 2
Foam Seal
8 GD24388 1 ASD Bulk Seed Tank, 55 Bushel
9 GD20922 2 Entrainer Mount Tap Block, Long
10 GD20923 2 Entrainer Mount Tap Block, Short
11 GA14038 1 ASD Front Tank Frame
12 GA14037 1 ASD Rear Tank Frame
13 GB0634
GB0635
GD19690-04
GD19690-03 1
1
1
1 ASD Entrainment Mount, 12 Row
ASD Entrainment Mount, 16 Row
Ribbon Sealer, 7'
Ribbon Sealer, 6½'
14 GD19893
GD19620 1
1 ASD Tank Mount Gasket, 12 Row
ASD Tank Mount Gasket, 16 Row
15 G11204 14 Flanged Whiz Lock Screw, ⅜"-16 x 1¼", Serrated
17 GA14040 1 Rear ASD Tank Mount
18 GD20037 1 Pin, 1" x 5⅜"
19 G10001
G10201 2
2 Hex Head Cap Screw, ⅜"-16 x 1"
Special Washer, ⅜" x 1½" O.D.
20 G10027
G11392 2
2 Hex Head Cap Screw, ¾"-10 x 2½"
Flat Washer, ¾" SAE
21 --- - See “ASD Entrainer Assembly, 12 Row” on page P95
See “ASD Entrainer Assembly, 16 Row” on page P97
22 GA15420 3 ASD Tank Mount
23 GD20035 2 Pin, 1½" x 11¼"
24 G10325
G10108 4
4 Hex Head Cap Screw, ⅜"-16 x 2¾"
Lock Nut, ⅜"-16
25 GD20036 1 Pin, 1½" x 7"
26 G10301 12 Carriage Bolt, ⅜"-16 x 1½"
27 GD27607 2 Ground Strap
28 G11204
G10529
G11249
G11528 1
1
1
1 Hex Serrated Flange Cap Screw, ⅜"-16 x 1¼", Grade 5
External Tooth Lock Washer, ⅜"
External Tooth Washer, ¼"
Hex Nut W/External Tooth Washer, ¼"-20
29 GD21308 2 Bolt Holder
A GA16997 - ASD Lid Seal Assembly, (Items 2 and 4-6)
Model 3660 M0217-02
Rev. 6/14 P104
