P120 – Kinze 3660 Lift and Rotate Planter Rev. 6/14 User Manual
Page 123
ITEM
PART NO.
QTY.
DESCRIPTION
1
A13794
A13959
1
-
Inner Hitch, 16 Row
(Non-Stock Item)
Inner Hitch, 12 Row
(Non-Stock Item)
2
GA12299
1
Hitch Catch
3
GD18888
G11387
G10001
1
3
3
Inner Hitch Hose Tray
Flat Washer, ⅜" SAE
Hex Head Cap Screw, ⅜"-16 x 1"
4
GD17765
G10468
1
2
Hitch Catch
Cotter Pin, ⅜" x 2"
5
GD3537-18
G11230
1
2
Shaft, 1¼" x 7⅜"
Retaining Ring
6
---
-
See "Tongue Cylinder" on page P175
7
GD5173
G10462
1
2
Pin, 1¼" x 5⅛"
Cotter Pin, 3/16" x 2"
8
GD18830
G11261
1
2
Inner Hitch Front Wear Pad
Hex Socket Head Cap Screw, ⅜"-16 x 1"
9
GD19366
GD19413
GD19465
G10037
G10108
4
2
2
4
2
Shim, ¼" Gauge (As Required)
Shim, 7 Gauge (As Required)
Shim, 12 Gauge (As Required)
Hex Head Cap Screw, ½"-13 x 1¼"
Lock Nut, ⅜"-16
10
GD20094
G10581
G11389
G10071
1
1
1
1
Bulkhead Bracket
Hex Head Cap Screw, ½"-13 x 2¼"
Flat Washer, ½" SAE
Serrated Flange Nut, ½"-13
11
GA13775
G10048
G11387
G10108
1
2
2
2
Hose Catch
Hex Head Cap Screw, ⅜"-16 x 2"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
12
GD19656
GD10538-15
G10980
G10111
1
2
2
2
Hose Retainer
Sleeve, ¾" O.D. x 2 ½" Long
Hex Head Cap Screw, ½"-13 x 5½"
Lock Nut, ½"-13
Inner Hitch, “Y”
Model 3660
M0217-02
Rev. 7/11
P120
