Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 125)

ITEM PART NO. QTY. DESCRIPTION
1 GA13963 1 Rear Hose Take-Up
2 GD19833 1 Rear Hose Take-Up Cover
3 G10328 8 Hex Head Cap Screw, ⅜"-16 x ⅝"
4 G11387 8 Flat Washer, ⅜" SAE
5 G10107 6 Lock Nut, ⅝"-11
6 G11391 6 lat Washer, ⅝" SAE
7 GB0218 6 Bushing, 21/32" I.D. x ⅞" O.D. x 19/32" Long
8 G10689 6 Carriage Bolt, ⅝"-11 x 2"
9 GA13962 1 Front Hose Take-Up
10 GD19825 1 Hose Take-Up Stop
11 G11091 2 Serrated Flange Nut, ⅜"-16
12 G10305 2 Carriage Bolt, ⅜"-16 x 1"
13 GD19832 1 Front Hose Take-Up Cover
14 GD19655 1 Hold Up Pin, ½"-13
15 G10111 1 Lock Nut, ½"-13
16 GA13655 1 Safety Lock-Up
17 GD19430
G10111
G11389
G10592
GD18071-03
GD19462 1
1
1
1
1
1 Lock-Up Latch Bracket
Lock Nut, ½"-13
Flat Washer, ½" SAE
Hair Pin Clip, No. 11
Silcon Rubber Tube
Compression Spring
18 GA13940 1 Detent Pin W/Chain
19 GD2558 1 Lynch Pin, ¼"
20 G4418-05 2 Edge Molding, 1/16" x 21¾"
A GA13657 - Safety Lock-Up Assembly (Items 16 and 17)
Hose Take-up, 12 Row
Model 3660 M0217-02
Rev. 7/11 P122
TM
