Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 13)

Ag Leader Electric Clutch
ITEM PART NO. QTY.
(Per Row)
DESCRIPTION
1 G3303-34
G3303-41 1
-
Chain, No. 41, 34 Pitch Including Connector Link (Pull Row Unit)
Chain, No. 41, 41 Pitch Including Connector Link (Push Row Unit)
2 G10620 2 Serrated Flange Nut, 5⁄16"-18
3 G10310 3 Carriage Bolt, ¼"-20 x ¾", Grade 2
4 GA16374 1 Electric Clutch
5 GA10151 1 Meter Drive Assembly Complete, 11/19 Tooth
6 GB0331 1 Clutch Adapter Plate
7 G10338 2 Carriage Bolt, 5⁄16"-18 x 1¼"
8 G10621 3 Serrated Flange Nut, ¼"-20
9 G10687 1 Hex Head Cap Screw, ⅜"-16 x 5½"
10 G11387 2 Flat Washer, ⅜" SAE
11 GD23773 1 Chain Idler Spacer
12 GD11962 1 Idler
13 GD1026 1 Sleeve, 13⁄16" Long
14 G11391 1 Flat Washer, ⅝" SAE
15 GD1065 1 Idler Spring
16 GD7318 1 Sleeve, 1" Long
17 G10201 1 Special Washer, ⅜" x 1½" O.D.
18 G10901 1 Lock Nut, ⅜"-16
19 G11091 3 Serrated Flange Nut, ⅜"-16
20 GD23774 3 Spacer
21 GA1720 1 Bearing/Sprocket, ⅞" Hex Bore
22 G10047 2 Hex Head Cap Screw, ⅜"-16 x 1¾"
23 G3303-88
G3303-78 1
-
Chain, No. 41, 88 Pitch Including Connector Link (Pull Row Unit)
Chain, No. 41, 78 Pitch Including Connector Link (Push Row Unit)
Model 3660 M0217-02
Rev. 8/12 P10
TM
