Shank Assembly, Seed Tube, and Depth Adjustment
ITEM
PART NO.
QTY.
(Per Row)
DESCRIPTION
1
GA10157
1
Shank W/Gauge Wheel Pivot Spindle And Set Screw
2
G11015
2
Hex Washer Head Cap Screw, ⅜"-16 x 1¼"
3
GB0274
1
Cover, Depth Adjustment
4
GD3612
1
Cap Plug
5
GB0266
1
Handle, Depth Adjustment
6
GD10993
1
Spring
7
GB0267
1
Lever, Depth Adjustment
8
GD13361
1
Pin, ⅜" x 1⅔"
9
GD11259
1
Sleeve, ⅜" I.D. x ⅝" O.D. x 125∕32" Long
10
GB0285
1
Collar, Depth Adjustment
11
G10207
1
Washer, ⅞" O.D. x 13∕32" I.D. x .134" (If Applicable)
12
G10669
1
Hair Pin Clip, No. 22
13
G10551
1
Clevis Pin, ¼" x 2½"
14
G11591
1
Nylon Lock Nut, ⅜"-24, Grade C
15
G11592
1
Hex Head Cap Screw, ⅜"-24 x 2¾", Grade 8
16
GD28390
1
Shield
17
G10312
2
Carriage Bolt, 5∕16"-18 x ¾"
18
G10620
2
Serrated Flange Nut, 5∕16"-18
19
GB0265
1
Pivot Link, Depth Adjustment
20
G10207
2
Washer, ⅞" O.D. x 13/32" I.D. x .134"
21
GD7318
1
Sleeve, 1" Long
22
GA15287
1
See “Planter Monitor Module (PMM)” on page P207
23
GA7975
1
See “Gauge Wheels” on page P13
24
G10108
4
Lock Nut, ⅜"-16
25
GD11845
1
Dust Cap
26
G10003
3
Hex Head Cap Screw, ⅜"-16 x 1½"
27
GD24545
2
Stop
28
GD1026
1
Sleeve, 13∕16" Long
29
G11387
2
Flat Washer, ⅜" SAE
30
G3303-98
G3303-108
G3303-16
G3303-114
G3303-124
GR0196
-
-
-
-
-
-
Chain, No. 41, 98 Pitch Including Connector Link (Mechanical)
Chain, No. 41, 108 Pitch Including Connector Link (EdgeVac)
Chain, No. 41, 16 Pitch Including Connector Link (Used W/Row Unit Extension Brackets)
Chain, No. 41, 114 Pitch Including Connector Link (Mechanical - 4 Center Rows Only)
Chain, No. 41, 124 Pitch Including Connector Link (EdgeVac - 4 Center Rows Only)
Connector Link, No. 41
31
GD23773
1
Chain Idler Spacer
32
GD11962
1
Idler
33
G10201
2
Special Washer, ⅜" x 1½" O.D.
34
G10438
1
Hex Head Cap Screw, ½"-13 x ¾"
35
GD1065
1
Idler Spring
36
GD16245
1
Sun Shade (Rubber)
37
G10687
1
Hex Head Cap Screw, ⅜"-16 x 5½"
38
GD17014
1
Hose Guide
39
G10047
G11387
G10108
1
2-3
1
Hex Head Cap Screw, ⅜"-16 x 1¾"
Flat Washer, ⅜" SAE
Lock Nut, ⅜"-16
