Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 215)

ITEM PART NO. QTY. DESCRIPTION
1 GA16831 1 ISOBUS Integra Display Cable
2 GD18176 1 Y-Splice Connector
3 GA12596 1 Radar Adapter Cable
4 --- Hall Effect Sensor
5 GA16826 - Implement Switch Extension Cable
6 --- - See “Valve Block - Located on R.H. Rear Center Frame (EdgeVac)” on page P184
See “Valve Block - Located on R.H. Rear Center Frame (Mechanical)” on page P183
7 GA12568 1 Seed Rate Cable
8 GA12564 1 Seed Rate Control Module
9 GA12537 1 Clutch Control Module
10 GA16382
GA16375 1
-
Section Adapter Cable, 12 Row (2 Row)
Section Adapter Cable, 16 Row (2 Row)
11 GA16374 - See “Ag Leader Electric Clutch” on page P9
12 GA16393
GA16381 -
- Interplant Cable (2 Rows)
Interplant Cable (3 Rows)
13 GA16383
GA16376 2
2 Clutch Cable (6 Connectors), 12 Row
Clutch Cable (8 Connectors), 16 Row
14 GA12558 1 Can Stub Cable, 8’’
15 GA12559 1 Can Extension Cable, 5’’
16 GA12566 1 Cab Stub Cable, 6” (Hydraulic Drive)
17 GA12567 1 Can Extension Cable, 4” (Hydraulic Drive)
18 GA16351 1 Planter Monitor Module
19 GA12557 1 PMM Cable
20 GA17544 1 Implement Cable
21 GA14450 1 CAN Adapter Cable
22 GA14452 1 Power Cable
23 GA12598 1 Seed Rate Power Cable
24 GA12540 1 Power Control Relay
25 GA16829 - See “Parallel Arms, Mounting Support Plate, and Quick Adjustable Down Forces
Springs Option” on page P7
26 *GA14447
*GA13554 -
- Integra Loaner Display (Display Only) (Shown)
Cobalt Display
* See “Miscellaneous Cobalt and Integra Parts” on page P200 for mounting brackets.
Model 3660 M0217-02
Rev. 8/12 P212
TM
Ag Leader Electric Clutch Package
