Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 175)

ITEM PART NO. QTY. DESCRIPTION
1 *D12226 1 O-Ring, No. 120
2 GD19316 1 Rod
3 *D12242 1 O-Ring, No. 345
4 *D12243 1 Back-Up O-Ring, No. 348
5 *D12255 1 U-Cup
6 *D12240 1 Wiper, 2"
7 GD12522 1 Gland
8 *D12106 1 Ring
9 G10939 1 Hex Head Cap Screw, ⅜"-16 x 2¼"
10 GD18528 1 Clevis
11 G10101 1 Hex Nut, ⅜"-16
12 G6400-08
GR1037 2
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
13 GA13556 1 Steel Hydraulic Line
14 GA8882
GR1517 2
-
Counter Balance Valve
Seal Kit For Counter Balance Valve, Includes: (3) O-Rings, (3) BU Rings
15 G10932 2 Hex Socket Head Cap Screw, 5/16"-18 x 2", Grade 8
16 G6408-08
GR1037 4
-
Plug W/O-Ring, ¾"-16 O-Ring
O-Ring
17 GD15623 1 Block
18 *D12239 1 O-Ring, No. 016
19 A13549 1 Barrell (Non-Stock Item)
20 GD27235 1 Nylon Lock Nut, 1"-14, Grade 8
21 GD12085 2 Ring
22 *D12086 1 Seal
23 *D12244 1 Seal
24 GD19261 1 Piston
A GA13548 - Cylinder Complete, 4½" x 48" (Part Number Stamped On Barrel)
B GR1927 - Seal Kit, Includes: (3) O-Rings, (1) Back-Up Ring, (1) U-Cup, (1) Wiper, (1) Piston
Ring, (2) Seals
*Part of seal kit, item can not be purchased individually.
Transport Lift Cylinder
Model 3660 M0217-02
Rev. 6/14 P172
