Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 183)

ITEM PART NO. QTY. DESCRIPTION
1 GD9905 1 Block
2 G6801-06
GR1045 2
-
Elbow W/O-Ring, 90°, 9/16"-18 Male JIC To O-Ring
O-Ring
3 G6400-06
GR1045 4
-
Connector W/O-Ring, 9/16"-18 Male JIC To O-Ring
O-Ring
4 G6500-06 2 Swivel Elbow, 90°, 9/16"-18 Male JIC To Female
5 G6801-08
GR1037 2
-
Elbow W/O-Ring, 90°, ¾"-16 Male JIC To O-Ring
O-Ring
6 G6400-10
GR1466 4
-
Connector W/O-Ring, ⅞"-14 Male JIC To O-Ring
O-Ring
7 G6400-08
GR1037 4
-
Connector W/O-Ring, ¾"-16 Male JIC To O-Ring
O-Ring
8 --- - See “Solenoid Valve” on page P186
9 GA3407 - Pressure Relief Valve, 1000 PSI
10 GD12818
G11068 1
2 Terminal Strip Mount
Phillips Flat Head Machine Screw, No. 10-24 x ⅝", Stainless Steel
11 GA9098
GD13310
G11065 1
2
2 Terminal Strip W/Screws, No. 6, 8 Terminal
Jumper, 7/16"
Phillips Pan Head Machine Screw, No. 8-32 x ⅝", Stainless Steel
12 G6408-H06-0
GR1045 2
-
Hex Socket Head Plug W/O-Ring, 9/16"-18
O-Ring
13 GD22691
G10004
G11387
G10229
G10101 1
4
8
4
4 Manifold Block Cover
Hex Head Cap Screw, ⅜"-16 x 1¼"
Flat Washer, ⅜" SAE
Lock Washer, ⅜"
Hex Nut, ⅜"-16
14 GA7023
G11326
G10108 1
2
2 Manifold Block Assembly
Carriage Bolt, ⅜"-16 x 5"
Lock Nut, ⅜"-16
A GR0764 - Pressure Relief Valve Seal Kit, Includes: (2) O-Rings, (1) BU Ring
Valve Block - Located on Hitch
Model 3660 M0217-02
Rev. 7/11 P180
TM
