Kinze 3660 Lift and Rotate Planter Rev. 6/14 - Manual (Page 101)

ASD Entrainer Assembly, 16 Row
ITEM PART NO. QTY. DESCRIPTION
1 GB0427
GD19665 12
3
ASD Seed Entrainer
ASD Spacer Plate
2 G10992 1 Serrated Flange Nut, No. 10-24
3 GB0444 2 ASD Shutoff Door Plug
4 G11464 1 Wing Nut, ¼”-20
5 GD19695 1 ASD Slide Latch
6 G11332 1 Hex Socket Head Set Screw, ¼” x No. 10-24 x ⅜”
7 GD19865
G10621 20
20 Eye Bolt, ¼”-20 x 1.47”
Serrated Flange Nut, ¼”-20
8 GB0433 4 ASD Seed Entrainer Door Section
9 GB0434 1 ASD Seed Entrainer End Cap
10 GD19508 8 Small O-Ring
11 GB0431 8 ASD Small Cap (If Applicable)
12 GD19698 1 ASD Chute Hanger, R.H.
13 GD19609
G10455 1
2 ASD Cleanout Door Hinge Rod
Cotter Pin, 1∕16” x ½”
14 GA14942 1 ASD Shutoff Door
15 G10316
GD19864 1
8 Carriage Bolt, ¼”-20 x 1”
Eye Bolt, ¼”-20 x 1.83”
16 GB0501 8 Latch Handle
17 GD21080 8 Cam Nut, ¼”-20
18 GB0502 4 ASD Cleanout Door
19 GD19619 1 ASD Cleanout Door Gasket
20 GD19699 1 ASD Chute Hanger, L.H.
21 G10103 21 Lock Nut, ¼”-20, Grade B
GD19614 10 Hex Head Cap Screw, ¼”-20 x 29”
G11328 11 Washer, ¼”
22 GB0436
GB0435 1
1 ASD Seed Entrainer Air Inlet, R.H. (Shown)
ASD Seed Entrainer Air Inlet, L.H.
23 GD19635 1 ASD Retainment Ring
24 GB0438 16 Air Orifice By-Pass
25 GD19808
G10001
G10622 1
3
3 Cleanout Chute Storage Bracket
Hex Head Cap Screw, ⅜"-16 x 1"
Serrated Flange Nut, ⅜"-16
26 GA14823 1 Cleanout Chute
27 GB0430 - ASD Large Cap
A GA13734 - ASD Entrainer Assembly, R.H. (Shown) (Items 1-24)
B GA13735 - ASD Entrainer Assembly, L.H. (Items 1-24)
