7 Visualization
70
Activate batch report for batch 3 and show if required:
 Chapter 16.2 "Barcode", page 264
Starting and ending batch report
If the batch report for start/end is configured using the barcode reader, it is started and ended
as follows.
Starting batch report:
Ending batch report:
BATCH3
Step Activity
1 Scan barcode for batch reporting (batch 1 to 9).
2 Scan Start.
Step Activity
1 Scan barcode for batch reporting (batch 1 to 9).
2 Scan Stop.
START
STOP
NOTE!
If batch reporting is stopped, texts that were activated using a barcode are reset to the default
text or retained in the current batch report, depending on the "Delete line" parameter.
The texts are saved in the completed batch report.
