2 Description
22
2.5
Use of the interfaces
Interface
Used for ...
USB device interface
•
Setup program
USB host interface 1
•
Connection of a USB memory stick
USB host interface 2
•
Connection of a USB memory stick
System bus In
•
Connection to base unit
•
Connection to router module
System bus Out
•
Connection to router module
LAN interface
•
Setup program
•
Web server
•
Mail server
Com1 interface
•
Connection to Modbus master device
•
Connection to Modbus slave devices
•
Connection of a barcode reader
•
Connection of a modem
Com2 interface
•
Connection to Modbus master device
•
Connection to Modbus slave devices
•
Connection of a barcode reader
•
Connection of a modem
