14 Configuration – in setup program only
246
Processing object features
Changes can be made directly to the object features in question using the processing functions
described above. It is also possible to open the object by double-clicking (in the process screen
or in the object list) in order to process the object features.
Moving objects
The user has the following options to move an object horizontally or vertically in the preview
screen:
•
Double-clicking the object to open it and changing the X/Y position.
• Left-clicking and holding the object and moving it directly in the process screen.
• Moving the object using the arrows.
Move object in process screen horizontally or vertically.
Clicking on this button opens an additional window. This contains different arrows
(buttons) for moving the object in preset steps.
Align object in the process screen (left, right, top, bottom).
Select the first object by clicking, keep the Shift key pressed, and click on another
object (or more) with the left mouse button. When you click on the appropriate button,
the other objects are aligned on the first object.
Without tool-
bar
Without toolbar (version 02)
By selecting this option ( ), the preview window is enlarged and corresponds to the
size of the process screen in the multifunction panel with deactivated toolbar.
All
Select layer and/or user group (drop-down menu) (version 02).
Only the objects of the selected layers and user groups are displayed in the preview
window.
Language
Select language (drop-down menu).
The object text is displayed in the selected language, provided it has already been
entered in this language when creating the object.
Button Function
