13 Configuration
13.18 NV connecting lists
In the NV connecting lists (analog and digital), the 54 analog inputs and the 54 digital inputs of
the multifunction panel are connected via the system bus using the signals of other modules.
In addition, the digital signals for controlling batch reporting (start/stop) are selected here.
The following chapters provide detailed lists of module signals:
 Chapter 13.18.3 "Analog signals (overview)", page 195
 Chapter 13.18.4 "Digital signals (overview)", page 197
Further information about the signals can be found in the operating manual for the relevant
module.
Status after change of configuration
The connections are available immediately.
Behavior after power on
The connections are available immediately after system initialization.
NOTE!
If the configuration is performed using the multifunction panel rather than the setup program,
the following must be observed:
The configuration menu of the multifunction panel does not contain any NV connecting lists.
Instead, a central NV connecting list is available in the configuration menu of the base unit
(CPU). The menu items "HMI analog inputs" or "HMI digital inputs" (incl. controlling batch re-
porting) are to be selected here.
