2 Description
 Multifunction panel:
V ISUALIZATION > C URRENT BATCH
Then change the batch if required and implement the edit by activating the yellow text
fields.
1
 Setup program:
HMI > C ONFIGURATION LEVEL > B ATCHES /P LANTS > B ATCH 1 TO 9 > B ATCH INFO > B ATCH
INFO 1 TO 10 > E DIT > T EXT RIGHT COLUMN
and
HMI > C
ONFIGURATION LEVEL > B ATCHES /P LANTS > B ATCH 1 TO 9 > B ATCH INFO > B ATCH
INFO 1 TO 10 > E DIT > F ACTORY SETTING
Batch number
Permanent changes to the batch number can only be made on the multifunction panel.
 Multifunction panel:
P ARAMETERIZATION > HMI > B ATCHES /P LANTS > B ATCH NUMBER 1 TO 9
It can be temporarily changed on the multifunction panel;
2
at the end of a batch, the internal
HMI batch number will be incremented and reactivated.
Batch start, end, duration
If the batch start, end, and duration are used, the lines can no longer be edited.
Batch selection
This function is used to directly select and display one of the active batches. Simply touch one
of the batch names displayed after calling up the function.
1
Only available if the respective batch parameter "Editable?" is set to Yes.
2
Only available if the respective batch parameter "Editable?" is set to Yes.
NOTE!
The function is only available if more than one batch is active.
