JUMO 705060 mTRON T - Multifunction Panel 840 Operating Manual - Manual (Page 236)

14 Configuration – in setup program only
236
Input time frame
Setup dialog
Parameter
Parameter Selection/settings Description
Destination Variable to which the entered value is written.
The value is seconds is determined from the time frame entered in the format
hh:mm:ss.
Inactive No variable selected.
Select module and corresponding vari-
able. The variable must be of the "Integer"
data type.
Minimum value Enter value
(00000:00:00 to 65535:59:58). Lower limit of the admissible input range
in the format hh:mm:ss
Maximum value Enter value
(00000:00:01 to 65535:59:59). Upper limit of the admissible input range
in the format hh:mm:ss
