AT-S80 Management Software User’s Guide
Section II: Using the Web Browser Interface 331
The Traffic Comparison Chart Page opens as shown in Figure 95.
Figure 95. Traffic Comparison Chart Page
3. To view traffic statistics, click on the arrow next to “Statistics” and
select one of the options in Table 7.
Table 7 Traffic Comparison Options
Option Definition
Inbound Octet Rate (Bytes/s) Measures the rate of inbound octet bits in bytes per
second.
Inbound Unicast Packet Rate (Pkts/s) Measures the rate of inbound unicast packets in
packets per second.
Inbound Non-unicast Packet Rate
(Pkts/s) Measures the rate of inbound non-unicast packets
(such as broadcast and multicast packets) in packets
per second.
