Chapter 25: Static Multicast Address Table
258 Section II: Using the Web Browser Interface
Modifying a Static Multicast Address Table
This procedure explains how to change the group number of the Static
Multicast Address Table.
To modify the group number in the Static Multicast Address Table,
perform the following procedure:
1. From the bookmarks on the left side of the page, select Bridge.
The Spanning Tree folder expands.
2. From the Spanning Tree folder, select Static Multicast.
The Static Multicast Address Table Page is shown in Figure 68 on
page 256.
3. Click modify next to the group number that you want to change.
The Modify Static Multicast Address Table Page is displayed. See
Figure 70.
Figure 70. Modify Static Multicast Address Table Page
4. Click the new Group Member number and deselect the original Group
Member number.
Note
To restore the previous Group Member number, click Restore.
5. Click Apply.
