Chapter 10: Virtual LANs
104 Section I: Using the Menus Interface
3. Type V to select 802.1Q VLAN.
The Tagged-based VLAN Configuration Menu is shown in Figure 22.
Figure 22. Tagged-based VLAN Configuration Menu
4. Type C to select Create VLAN.
The VLAN Creation Menu is shown in Figure 22.
5. From the VLAN Management Menu, type C to select Create VLAN.
VLAN Management Menu -> Tagged-based VLAN Configuration
VLAN ID VLAN Name VLAN Type
------- ------------------------------- ---------
1 Default VLAN Permanent
2 Sales Static
----------------------- ------------------------------------
[N]ext Page
[C]reate VLAN C[o]nfig VLAN Member
[P]revious Page [D]elete VLAN [S]et Port Config
[R]eset VLAN to Default [Q]uit to Previous Menu
Command>
