AT-S80 Management Software User’s Guide
Section I: Using the Menus Interface 193
Configuring 802.1x Port-based Network Access Control Feature
To configure 802.1x Port-based Network Access Control feature, perform
the following procedure:
1. From the Main Menu, type A to select Advanced Switch
Configuration.
The Advanced Switch Configuration Menu is shown in Figure 14 on
page 64.
2. From the Advanced Switch Configuration Menu, type X to select
802.1x Port Based Access Control Configuration.
The Port Based Access Control Configuration Menu is shown in
Figure 47.
Figure 47. Port Based Access Control Configuration Menu
Advanced Switch Configuration -> Port Based Access Control Configuration Menu
NAS ID : Nas1
Authentication Method : 1
Port No : 1
Port Status : Authorized
Port Control : Force Authorized
Transmission Period : 30 seconds
Maximum Request : 2
Quiet Period : 60 seconds
Re-authentication Period : 3600 seconds
Re-authentication Status : Disabled
Multi-host : Disabled
Current PVID : 1
Guest VLAN ID : Disabled
----------------------- ------------------------------------
[N]AS ID
[M]aximum Request [I]nitialize Port
[N]ext Page Q[u]iet Period [G]uest VLAN ID
Pre[v]ious Page R[e]-auth Period Auth [M]ode
[P]ort No Re-[a]uth Status Aut[h]entication Method
Port [C]ontrol Multi-h[o]st [Q]uit to previous Page
[T]ransmission Period
Command>
