Allied Telesis AT-S80 - Manual (Page 209)

AT-S80 Management Software User’s Guide
Section I: Using the Menus Interface 209
The Software Upgrade Menu is shown in Figure 50.
Figure 50. Software Upgrade Menu (1 of 2)
3. Type T to select TFTP Upgrade.
The Software Upgrade Menu (2 of 2) is shown in Figure 51.
Figure 51. Software Upgrade Menu (2 of 2)
4. Type S to select Set TFTP Server IP Address.
The following prompt is displayed:
Enter IP address of TFTP server:
Switch Tools Configuration -> Software Upgrade Menu
[T]FTP Software Upgrade
[Q]uit to previous menu
Command>
Main Menu -> Software Upgrade Menu
Image Version/Date: AT-S80 V2.0.0 [1.1.1.57/Dec 6 2007 14:39:48
TFTP Server IP: 0.0.0.0
Image File Name: FS750_1_1_1_57
Retry Count: 5
---------------------- -------------------------
Set TFTP [S]erver IP Address
Set Image [F]ile Name
[U]pgrade Image and Reboot
Set [R]etry Count
[Q]uit to previous menu
Command>
