Page 75

#3
HDLM supports an environment where an IPF kernel is installed on a
system that uses an Intel CPU.
#4
Note the following in an EM64T/AMD64 environment:
¢
HDLM supports an environment where an EM64T/AMD64 kernel is
installed on a system that uses an Intel CPU or AMD Opteron CPU.
¢
In an EM64T/AMD64 environment, the RPM (Red Hat Package
Manager) packages listed below are required. Install these RPM
packages before installing HDLM:
- libstdc++-RPM-package-version.i386.rpm
- libgcc-RPM-package-version.i386.rpm
- glibc-RPM-package-version.i686.rpm
RPM-package-version depends on the OS version you are using.
Table 3-3 Red Hat Enterprise Linux 5 Kernels Supported by HDLM
Kernel architecture
#1
Kernel
IA32
#2
2.6.18-8.el5
2.6.18-8.el5PAE
2.6.18-53.el5
2.6.18-53.el5PAE
2.6.18-92.el5
2.6.18-92.el5PAE
2.6.18-128.el5
2.6.18-128.el5PAE
2.6.18-164.el5
2.6.18-164.el5PAE
2.6.18-194.el5
2.6.18-194.el5PAE
2.6.18-238.el5
2.6.18-238.el5PAE
2.6.18-274.el5
2.6.18-274.el5PAE
IPF
#3
2.6.18-8.el5
2.6.18-53.el5
2.6.18-92.el5
2.6.18-128.el5
2.6.18-164.el5
2.6.18-194.el5
Creating an HDLM Environment
3-7
Hitachi Dynamic Link Manager User Guide (for Linux(R))
