Execute the HDLM-configuration definition utility dlmcfgmgr with the -v
parameter specified:
# dlmcfgmgr -v
HDevName Management Device Host Channel Target Lun
/dev/sddlmaa configured /dev/sdh 1 0 0 0
/dev/sdo 2 0 0 1
KAPL10302-I /sbin/dlmcfgmgr completed normally.
The HDevName and Device columns display HDLM devices and SCSI
devices, respectively.
7
.
Create an md device.
Based on the correspondence between the HDLM devices and SCSI
devices checked in step 6, create an md device.
When you specify a device name, you must also specify the partition
number that is displayed in step 4.
# mdadm -C /dev/md0 -llinear -f -n1 /dev/sddlmaa1
mdadm: /dev/sddlmaa1 appears to contain an ext2fs file system
size=5238528K mtime=Wed Feb 6 19:17:08 2008
mdadm: /dev/sddlmaa1 appears to be part of a raid array:
level=-4 devices=2 ctime=Wed Feb 6 19:16:07 2008
Continue creating array? y
mdadm: array /dev/md0 started.
8
.
Create a configuration file.
Execute the following command to add an md device definition to the
existing configuration file /etc/mdadm.conf:
# mdadm --detail --scan | grep -w “/dev/md0” >> /etc/mdadm.conf
The following example shows the contents of the created configuration
file:
The underlined part indicates the lines added in this step.
# cat /etc/mdadm.conf
DEVICE /dev/sdo1 /dev/sdh1
ARRAY /dev/md0 level=multipath num-devices=2 UUID=6b2ec21b:
06d0f50b:bbf04d32:1e00b09a auto=yes
ARRAY /dev/md0 level=linear num-devices=1 UUID=426a9f1c:
9cfa6310:6aa9a80b:11ea2102
For details about the contents of the configuration file, see the Linux
documentation or use the man command.
9
.
If the configuration file /etc/mdadm.conf has been recreated, delete the
unnecessary ARRAY line in that configuration file.
Delete the ARRAY line that includes the same name as the md device
name (md0) created in step 8. In the following example, the underlined
lines are to be deleted.
# cat /etc/mdadm.conf
3-164
Creating an HDLM Environment
Hitachi Dynamic Link Manager User Guide (for Linux(R))
