5. To move the message window to other locations on your desktop, click and drag it
to another area or double-click it to automatically undock it from the Replication
Console.
Viewing the log file through a text editor
The log files can be viewed, from the location where Storage Mirroring Recover is
installed, with a standard text editor.
The following table describes the information found in each column of the log file.
Column
Number
Description
1 The date the message was generated
2 The time the message was generated.
3 The process ID.
4 The thread ID.
5
The sequence number is an incremental counter that assigns a unique
number to each message.
6
The type or level of message displayed.
●
1—Warning or error message
●
2—Informational message
7 The message ID.
8 The message text.
Sample Storage Mirroring Recover log file
01/15/2009 14:14:18.3900 95 98 2 2 69 Kernel Started
01/15/2009 14:14:18.4200 95 98 3 2 10004 Valid Activation Key Detected :
01/15/2009 14:14:18.5350 98 170 4 2 52501 Target module loaded successfully
01/15/2009 14:14:18.6760 98 172 5 2 10004 Valid Activation Key Detected :
01/15/2009 14:14:18.9870 130 131 6 2 51501 Source module loaded successfully
01/15/2009 14:24:15.2070 130 132 7 2 72 Connection Request from
ip://206.31.4.305
01/15/2009 14:24:16.3090 131 133 8 2 600002 Unified login provides ADMIN
access
01/15/2009 14:24:40.9680 132 134 9 2 99 RepSet Modified: UserData
01/15/2009 14:25:22.4070 134 131 10 2 71 Originator Attempting
