GSP-930 Programming Manual
20
Sweep settings Sweep icon that shows the sweep
status.
Trigger settings Trigger icon that shows the trigger
status.
Pre-amp settings Pre-amplifier icon that shows the
Pre-amplifier status.
Trace and
detection settings Trace icon that shows the trace type
and the detection mode used for
each trace.
Status Icons Displays the interface status, power source status,
and alarm status, etc. See the Status Icon Overview
on page 21 for a list of the status icons.
Frequency/
Bandwidth
settings Displays the Start, Center and Stop frequencies,
RBW, VBW, Span and Sweep settings.
Entry/Message
area This area is used to show system messages, errors
and input values/parameters.
Trace and
waveforms Main display showing the input signals, traces,
limit lines and marker positions.
