GSP-930 Programming Manual
98
Query Syntax :DISPlay:DEMod[:WINDow]:TRACe:X[:SCALe]:AUTO?
Parameter 0 Turn Auto Scale off.
1 Turn Auto Scale on.
OFF Turn Auto Scale off.
ON Turn Auto Scale on.
Return parameter 0 Auto Scale is off.
1 Auto Scale is on.
Example :DISP:DEM:TRAC:X:AUTO ON
:DISPlay:DEMod[:WINDow]:TRACe:X
[:SCALe]:PDIVision
Set
Query
Description Sets or queries the time axis scale/div.
Syntax :DISPlay:DEMod[:WINDow]:TRACe:X[:SCALe]:
PDIVision
Query Syntax :DISPlay:DEMod[:WINDow]:TRACe:X[:SCALe]:
PDIVision?
Parameter
Return parameter Seconds
Example :DISP:DEM:TRAC:X:PDIV 2 ms
:DISPlay:DEMod[:WINDow]:TRACe:X
[:SCALe]:RPOSition
Set
Query
Description Sets or queries the Reference Position of the trace
for AM/FM demodulation (x-axis grid division).
Syntax :DISPlay:DEMod[:WINDow]:TRACe:X[:SCALe]:
RPOSition
Query Syntax :DISPlay:DEMod[:WINDow]:TRACe:X[:SCALe]:
RPOSition?
Parameter/
Return parameter 1~10
Example :DISP:DEM:TRAC:X:RPOS 2
