GSP-930 Programming Manual
104
:DISPlay[:WINDow]:TRACe:Y[:SCALe]:
NRPosition
Set
Query
Description Sets or queries the position of the normalized
reference level. The 0~10 Y-axis grid divisions
correspond to the bottom~top grid divisions.
Syntax :DISPlay[:WINDow]:TRACe:Y[:SCALe]:NRPosition
Query Syntax :DISPlay[:WINDow]:TRACe:Y[:SCALe]:NRPosition?
Parameter/
Return parameter 0~10
Example :DISP:TRAC:Y:NRP 5
:DISPlay[:WINDow]:TRACe:Y[:SCALe]
:PDIVision
Set
Query
Description Sets or queries the Y-axis scale/div when the
amplitude scale is logarithmic.
Syntax :DISPlay[:WINDow]:TRACe:Y[:SCALe]:PDIVision{1|2|5|
10}
Query Syntax :DISPlay[:WINDow]:TRACe:Y[:SCALe]:PDIVision?
Parameter/
Return parameter 1 1 dB
2 2 dB
5 5 dB
10 10 dB
Example :DISP:TRAC:Y:PDIV 10
:DISPlay[:WINDow]:TRACe:Y[:SCALe]:
POSition
Set
Query
Description Sets or queries the position of the on-screen scale.
Syntax :DISPlay[:WINDow]:TRACe:Y[:SCALe]:POSition
{LEFT|CENTer|RIGHt}
