3.3 Displaying the Data Logging Status, and Deleting the Data File List
Displaying the Logging Data
Procedure
Current data Pause updating
Display selected data files
Stop Updating of the List of Logged Files
1. Click Updating pause on the toolbar or choose View > Updating pause of the
data file list from the menu bar.
Even if the logging status of the data files currently being logged is Stop, those
files do not appear in the list of logged files.
Restart Updating of the List of Logged Files
2. If you repeat step 1, the logged data files after stopping the update are displayed
in the list of logged data files.
Displaying Data Files Currently Being Logged in Data Viewer
1. Click Current Data on the toolbar or choose View > Current Data File from the
menu bar.
Data Viewer starts, and only the data being saved at that point is displayed.
Displaying Logged Data Files in Data Viewer
1. Drag in the list of logged data files to select the items you wish to display.
2. Click Display selected Data files on the toolbar or choose View > Selected Data
Files from the menu bar.
The selected data files are all displayed in the viewer.
Note
You can quickly display a file in the viewer by double-clicking the data file (see chapter 5).
Clearing the Data File List
1. Choose View > Erase the data file list.
The data file list is cleared. The list cannot be redisplayed once it has been
cleared.
