5-34 IM WX13-01E
5.9 Exporting Data
You can extract (copy) a section of a data file and save the result. This operation does
not change the original data.
Procedure
1. Select the range of data to be extracted by using cursors.
2. Choose Export from the Convert menu.
The Export dialog box opens.
3. The range that was selected by the cursors is indicated in the Start and End
boxes using data numbers. The logging time is displayed to the right of the text
box.
To change the data range to be exported, enter values in the appropriate boxes.
4. Click File to open the Change the file name dialog box. Change the file name and
destination as necessary and click OK.
Note
The default file name is as follows:
Original file name-first data number (8 digits) of the range to be exported.mld.
5. Click OK to create the file and close the dialog box. Click Cancel to close the
dialog box without creating the file.
