IM 11M12D01-01E 2-10
2.3.2 ZO21P-H Adapter for High-Temperature Probe
The probe adapter is used to lower the sample gas to a temperature below 700
ЊC (below
300
ЊC at probe adapter surface) before it is fed to the detector.
Insertion length: 1 m, 1.5 m
Material in Contact with Gas:
SUS 316 (JIS), Zirconia, SiC or SUS 310S, SUS 304(JIS) (flange)
Probe Material: SiC, SUS 310S (JIS)
Installation: Flange mounting (FF type or RF type)
Probe Mounting Angle: Vertically downward within
Ϯ5Њ
Where the probe material is SUS 310S, horizontal mounting is available.
Construction: Non explosion-proof. Rainproof construction
Weight: Insertion length of 1.0 m: approx. 6.5 kg (JIS) / approx. 8.5 kg (ANSI)
Insertion length of 1.5 m: approx. 7.5 kg (JIS) / approx. 9.5 kg (ANSI)
Sample gas temperature: 0 to 1400
ЊC (when using SiC probe) 0 to 800ЊC (when
using SUS 310S probe adapter)
Sample gas pressure: -0.5 to + 5 kPa. When using in the range of 0 to 25 vol% O
2
or
more, the sample gas pressure should be in the range of -0.5 to +0.5 kPa.
(Where the sample gas pressure for the high-temperature probe is
negative, an auxiliary ejector is necessary.)
᭹ Model and Codes
-100
-150
*A
-J
-N
-M
-L
-A
-R
-Q
-T
-S
-E
-H
-A
-B
T2.3E.EPS
Model Suffix code
Option
code
ZO21P
Material
Insertion
length
Flange
High Temperature Probe Adapter
SiC
SUS 310S
1.0 m
1.5 m
JIS 5K 50 FF SUS304
JIS 10K 65 FF SUS304
JIS 10K 80 FF SUS304
JIS 10K 100 FF SUS304
ANSI Class 150 4 RF SUS304
ANSI Class 150 2 1/2 RF SUS304
ANSI Class 150 3 RF SUS304
JPI Class 150 3 RF SUS304
JPI Class 150 4 RF SUS304
DIN PN10 DN50 A SUS304
Style A
Description
Style code
.......................................
.....................................
.....................................
...............................
...............................
.............................
............................
............................
............................
............................
............................
............................
............................
............................
............................
......................
