8) Maintenance display
From the menu on the Execution/Setup display, select Maintenance. The Maintenance
display will appear. The following can be performed from the menu on this display.
1. Display setup
2. Calibration, indication check, and blowback setups
3. mA-output loop and contact checks
4. Channel card power
9) Commissioning display
From the menu on the Execution/Setup display, select Commissioning. The Commis-
sioning display where parameter setups can be selected will appear. The following can
be selected from the menu on this display.
1. Selection of detectors and sample gases
2. Analog output setup
3. Alarm setup
4. Contact input/output setup
5. Average group setup
6. Others — clock setup, password setup, etc.
Enter
Maintenance
Display setup
F10E.EPS
᭜
Calibration setup
᭜
Indication check setup
᭜
Blow back setup
᭜
mA-output loop check
᭜
Contact check
᭜
Channel card power
Enter
Commissioning
Basic setup
F11E.EPS
᭜
mA-output setup
᭜
Alarm setup
᭜
Contact setup
᭜
Average group setup
᭜
Others
Figure 6.14 Maintenance Display Figure 6.15 Commissioning Display
6.2.2.5 Entering Numeric and Text Data
This section sets out how to enter numeric and text data. If only numeric values are
entered, a numeric-data entry display as in Figure 6.16 then appears. Press the numeral
keys to enter numeric values. If those values include a decimal point as in Figure 6.16,
the decimal point need not be entered because the decimal point position is already
fixed, so just enter 00098.
Enter
New value: 000.98 % O2
0
1
4
7
2
3
5
6
8
9
F7.4E.EPS
Figure 6.16 Numeric-data Entry Display
