Table 10.7 Initialization Parameters and Defaults -part1
T10.7E.eps
Mode Manual
Points Span - Zero
Zero gas concentration 1.00% O 2
Span gas concentration 21.00% O 2
Minimum 0% O 2
Maximum 25% O 2
Output smoothing time constant 0 sec (disabled)
Output mode Linear
During warmup 4 mA
Preset value 4 mA
Under maintenance Last measured value
Preset value 4 mA
Under calibration, Indication check, During Blowback Last measured value
Preset value 4 mA
Error Last measured value
Preset value 4 mA
Group invalid 4 mA
Preset value 4mA
Process alarm Last measured value
Preset value 4mA
Item Initialization Parameter Default
Display
Tag name Deleted
T
rend Graph Displayed channels All ON
Sampling interval 30 sec
Graph upper limit 25.0% O 2
Graph lower limit 0.0% O 2
Auto Return Time 0 min. (disabled)
Display contrast Medium
Display Auto power off 0 min (disabled)
Display language Not affected
CAL
Indication Check
Hold time 3 min. 00 sec
Calibration / Indication check time 3 min . 00 sec.
Calibration / Indication check interval 1 day 00 hrs.
Start date (day/month/year) 01 / 01 / 01
Start time 00 : 00
Blowback
Mode No function (disabled)
Hold time 3 min 00 sec
Blowback time 10 min 00 sec
Blowback interval 30 days 00 hours
Start date (day/month/year) 01 / 01 / 01
Start time 00 : 00.
mA - output
Output range
Output holod setting
