IM 11M12D01-01E 8-23
8. Detailed Data Setting
1) Touch the Setup key on the basic panel display, and the [Execution/Setup] display
appears.
2) Select [Commissioning] and the Commissioning display appears.
3) Select [Others] then [Fuel Setup] and the display of Fig. 8.21 appears.
4) Select [Content of moisture in exhaust gas] and [Theoretical air quantity] in turn and
enter numeric data.
5) Select [more] and touch Enter key, and a display like Fig. 8.22 is displayed. Here
enter [Value of the X coefficient] and [Absolute humidity of the atmosphere] then
select [finished] to revert to the display of Fig. 8.21.
Enter
Fuel setup
F8.23E.EPS
᭜
Theoretical air quantity
required: 1. 0 0 m3/kg
᭜
more. . . . . .
Contents of moisture in
exhaust gas: 0. 0 0 m3/kg
See Manual for details
!
Enter
Fuel setup
F8.24E.EPS
᭜ Absolute humidity of the
atmosphere:
0. 0 0 0 0 kg/kg
᭜ finished.
Value of the X coefficient:
1. 0 0
Fig. 8.21 "Fuel Setup" display 1 Fig. 8.22 "Fuel Setup" display 2
< Default setting>
Fuel parameters are set to defaults in Table 8.8 prior factory shipment or after data
initialization..
Table 8.8 Default values of "Fuel" settings
Item Default setting
Amount of water vapor in exhaust gas 0.00 m3/kg (m3)
Theoretical amount of air 1.00 m3/kg (m3)
X value 1.00
Absolute humidity of the atmosphere 0.0 kg/kg
T8.9E.ESP
