IM 11M12D01-01E 7-14
7.11 Checking Operation of Contact Input, Contact Output
After wiring the cables you can perform a contact I/O check to display the status of
contact inputs and to check the operation of contact outputs including contact outputs to
operate solenoid valves during autocalibration.
7.11.1 Contact Output Operation Check
1) Touch [Setup] on the touchdisplay to switch to the [Execution/Setup] display.
2) Select [Maintenance] and touch the [Enter] key.
3) From the Maintenance display select [Contact check], and touch the [Enter] key.
4) The Contact check display shown in Fig. 7.18 allows you to select contacts to check.
To check the individual error contacts for channels 1 to 8, select [Output contact
ch(Channel contact output)] or to select Function contacts (contacts 1 to 5) select
[Output contact ctrl(Common contact outputs)].
5) Next the Contact no. select display is displayed. Select the contact you want to check,
then touch the Enter key, and the [OFF] / [On] selection window opens. Select then
touch the Enter key to open or close the corresponding contact output.
Enter
᭜ Output contact ctrl
᭜ Solenoid valve contacts
᭜
Input contacts
F28E.EPS
Contact check
Output contact ch.
Enter
Ch1 :
᭜ Ch2 : ON
᭜ Ch3 : OFF
᭜
Ch4 : OFF
᭜
Ch5 : OFF
᭜ Ch6 : OFF
᭜
Ch7 : OFF
᭜
Ch8 : OFF
F7.19E.EPS
Output contactch
OFF
Fig. 7.18 Contact check Fig. 7.19 Contact select
Note
1) Individual error contacts do not operate if corresponding channel is not installed.
2) If you perform a Channel Contact Output Open / Close check then Error2 is gener-
ated. The reason is that Channel Contact Output is used as Sensor heater power safety
switch, and this turns off power to the heater. If this error occurs, to reset it remove
the channel card then reinsert it (hot swap functions), or turn power OFF then back
ON.
