Watlow EZ-ZONE ® RME Module • 94 • Chapter 6 Features
Counter Function
Function counts up or down from Load Value and produces
Output Value = On when Count = Target Value.
Note:
Count value clears on power loss.
Load Value restored on power up.
Counter Operation:
Whenever a prescribed clock transition occurs with-
out an error on source B the count will be equal to
the Load Value.
If Function is an Up Counter:
Whenever a prescribed clock transition occurs with-
out an error on Source A the count will increment by
+1. If the count is equal to 9,999 when the transition
occurs count will be 1 after transition.
If Function is a Down Counter:
Whenever a prescribed clock transition occurs with-
out an error on Source A the count will decrement by
-1. If the count is equal to 0 when the transition oc-
curs the count will be 9,999 after transition.
An error, when read, can indicate any of the following:
None, Open, Shorted, Measurement Error, Bad Cal Data,
Ambient Error, RTD Error, Fail, Math Error, Not Sourced,
Stale
[SFn;A] Source Function A (Clock) : None, Alarm, Compare, Counter,
Digital I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
[SFn;b] Source Function B (Load) : None, Alarm, Compare, Counter,
Digital I/O, Profile Event Out A to H, Function Key, Logic, Timer, Variable
[`S2;A] Source Zone A : 0 to 16
[`S2;b] Source Zone B : 0 to 16
[`Si;A] Source Instance A : 1 to 250
[`Si;b] Source Instance B : 1 to 250
[trgt] Target Value : 0 to 9,999
[`LAt] Latching : No, Yes
[SAS;b] Source Active State B (Active State Load) : High, Low
[LoAd] Load Value : 0 to 9,999
[``Fn] Function : Up, Down
[SAS;A] Source Active State A (Active State Clock) : High (rising), Low
(falling), Both (rising & falling)
Output Value
Error
Source Value A
Source Value B
Counter
Overview
Instances - 8 per RME
Function
Source
Active State
A
Source
Active State
B
Source Function A
Source Instance A
Source Zone A
Source Error A
Source Function B
Source Instance B
Source Zone B
Source Error B
Load
Value
Target
Value
Latching
Count
[`Ctr] Counter Menu
[`SEt] Setup Page
[`Su;A] Source Value A : Off, On
[`Su;b] Source Value B : Off, On
[``o;u] Output Value : Off, On
[`Cnt] Count : 0 to 9,999
[`Ctr] Counter Menu
[`SEt] Operation Page
Custom Function
Custom
Overview
Instances - 20 per RME
[`PAr] Parameter : None, Display Units,
User Settings Restore, Alarm Low Set Point,
Alarm High Set Point, Alarm Hysteresis,
Custom
[`iid] Instance ID : 1 to 24
Instance ID
Parameter
[CUSt] Custom Menu
[FAct] Factory Page
Diagnostic Function
This function allows the user to view module specific infor-
mation that may be useful when troubleshooting.
Diagnostics
Overview
Instances - 1 per RME
[`rEu] Software Revision: 1.00, ...
[S;bLd] Software Build Number : 0, 1, 2, ...
[``Sn] Serial Number : xxxxxx
[dAtE] Date of Manufacture : YWW format
[``Pn] Part Number: scrolls on display
Hardware ID : 24 or 117 (RME)
Device Status : OK, Fail
[diAg] Diagnostics Menu
[FAct] Factory Page
Part Number
Software Revision
Software Build Number
Serial Number
Date of Manufacture
Hardware ID
Device Status
Device Name
Device Name : EZ-ZONE RM
