Watlow EZ-ZONE ® RME Module • 30 • Chapter 3 Operations Page
Chapter 3: Operations Pages
3
[`dio]
[oPEr]
Digital Input/Output Menu
[```1]
[`dio]
Digital Input/Output (1 to 24)
[`do;S] Output State
[`di;S] Input State
[`ACt]
[oPEr]
Action Menu
[```1]
[`ACt]
Action (1 to 8)
[`Ei;S] Event Status
[ALM]
[oPEr]
Alarm Menu
[```1]
[ALM]
Alarm (1 to 8)
[`A;Lo] Low Set Point
[`A;hi] High Set Point
[a;Clr] Clear Request
[a;sir] Silence Request
[`a;st] State
[CUrr]
[oPEr]
Current Menu
[```1]
[CUrr]
Current (1 to 4)
[`C;hi] High Set Point
[`C;Lo] Low Set Point
[`CU;r] RMS Read
[`C;Er] Error
[`h;Er] Heater Error
[`Lnr]
[oPEr]
Linearization Menu
[```1]
[`Lnr]
Linearization (1 to 8)
[`Su;A] Source Value A
[oFSt] Offset
[``o;u] Output Value
[`CPE]
[oPEr]
Compare Menu
[```1]
[`CPE]
Compare (1 to 8)
[`Su;A] Source Value A
[`Su;b] Source Value B
[``o;u] Output Value
[tMr]
[ oPEr] Timer Menu
[```1]
[tMr]
Timer (1 to 8)
[`Su;A] Source Value A
[`Su;b] Source Value B
[``E;t] Elapsed Time
[``o;u] Output Value
[`Ctr]
[oPEr]
Counter Menu
[```1]
[`Ctr]
Counter (1 to 8)
[`Cnt] Count
[`Su;A] Source Value A
[`Su;b] Source Value B
[``o;u] Output Value
[`LgC]
[oPEr]
Logic Menu
[```1]
[`LgC]
Logic (1 to 8)
[`Su;A] Source Value A
[`Su;b] Source Value B
[`Su;C] Source Value C
[`Su;d] Source Value D
[`Su;E] Source Value E
[`Su;F] Source Value F
[`Su;g] Source Value G
[`Su;h] Source Value H
[``o;u] Output Value
[MAt]
[oPEr]
Math Menu
[```1]
[MAt]
Math (1 to 8)
[`Su;A] Source Value A
[`Su;b] Source Value B
[`Su;C] Source Value C
[`Su;d] Source Value D
[`Su;E] Source Value E
[``o;u] Output Value
[oFSt] Offset
[`SoF]
[oPEr]
Special Output Function Menu
[```1]
[`SoF]
Special Output Function (1 to 4)
[`Su;A] Source Value A
[`Su;b] Source Value B
[`ou;1] Output Value 1
[`ou;2] Output Value 2
[`ou;3] Output Value 3
[`ou;4] Output Value 4
Operation Page Parameters
To navigate to the Operations Page using the RUI, fol-
low the steps below:
1. From the Home Page, press both the Up ¿ and
Down ¯ keys for three seconds. [``Ai] will appear
in the upper display and [oPEr] will appear in the
lower display.
2. Press the Up ¿ or Down ¯ key to view available
menus.
3. Press the Advance Key ‰ to enter the menu of
choice.
4. If a submenu exists (more than one instance), press
the Up ¿ or Down ¯ key to select and then press
the Advance Key ‰ to enter.
5. Press the Up ¿ or Down ¯ key to move through
available menu prompts.
6. Press the Infinity Key ˆ to move backwards
through the levels: parameter to submenu; submenu
to menu; menu to Home Page.
7. Press and hold the Infinity Key ˆ for two seconds to
return to the Home Page.
On the following pages, top level menus are identified
with a yellow background color.
Note:
Some of these menus and parameters may not appear, depending on the controller's options. See model number
information in the Appendix for more information. If there is only one instance of a menu, no submenus will ap-
pear.
Note:
Some of the listed parameters may not be visible. Parameter visibility is dependent upon controller part number.
