Watlow EZ-ZONE ® RME Module • 63 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[sfn;D]
[SFn.d] Logic (1 to 8)
Source D
Set the type of function
that will be used for this
source.
[none] None (61)
[ALM] Alarm (6)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out
A (233)
[Ent;b] Profile Event Out
B (234)
[Ent;C] Profile Event Out
C (235)
[Ent;d] Profile Event Out
D (236)
[Ent;E] Profile Event Out
E (247)
[Ent;F] Profile Event Out
F (248)
[Ent;g] Profile Event Out
G (249)
[Ent;h] Profile Event Out
H (250)
[`FUn] Function Key
(1001)
[lim] Limit (126)
[`lgC] Logic (239)
[SoF;1] Special Function
Output 1 (1532)
[SoF;2] Special Function
Output 2 (1533)
[SoF;3] Special Function
Output 3 (1534)
[SoF;4] Special Function
Output 4 (1535)
[tMr] Timer (244)
[`uAr] Variable (245)
None 3026
[offset 80]
0x7F (127)
1 to 8
4
- - - - 27004 uint
RWES
[`si;D]
[ Si.d] Logic (1 to 8)
Source Instance D
Set the instance of the
function selected above.
1 to 250 1 3042
[offset 80]
0x7F (127)
1 to 8
0x0C (12)
- - - - 27012 uint
RWES
[`s2;D]
[ SZ.d] Logic (1 to 8)
Source Zone D
Set the zone of the function
selected above.
0 to 16 0 3058
[offset 80]
0x7F (127)
1 to 8
0x14 (20)
- - - - 27020 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
