Watlow EZ-ZONE
®
RME Module
•
58
•
Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[sas;A]
[SAS.A]
Counter (1 to 8)
State Active Source A
Set what output state will
indicate on.
[both]
Both (130
[high]
High (37)
[LoW]
Low (53)
High
4480
[offset 40]
0x82 (130)
1 to 4
0xB (11)
- - - -
30011
uint
RWES
[sfn;B]
[SFn.b]
Counter (1 to 8)
Source Function B
Set the type of function
that will be used for this
source which is the counter
load signal.
[none]
None (61)
[ALM]
Alarm (6)
[`C;Pr]
Cool Power, Control
Loop (161)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out
A (233)
[Ent;b]
Profile Event Out
B (234)
[Ent;C]
Profile Event Out
C (235)
[Ent;d]
Profile Event Out
D (236)
[Ent;E]
Profile Event Out
E (247)
[Ent;F]
Profile Event Out
F (248)
[Ent;g]
Profile Event Out
G (249)
[Ent;h]
Profile Event Out
H (250)
[`FUn]
Function Key
(1001)
[`lgC]
Logic (239)
[tMr]
Timer (244)
[`uAr]
Variable (245)
None
4462
[offset 40]
0x82 (130)
1 to 4
2
- - - -
30002
uint
RWES
[`si;B]
[ Si.b]
Counter (1 to 8)
Source Instance B
Set the instance of the
function selected above.
1 to 250
1
4466
[offset 40]
0x82 (130)
1 to 8
4
- - - -
30004
uint
RWES
[`s2;B]
[ SZ.b]
Counter (1 to 8)
Source Zone B
Set the zone of the function
selected above.
0 to 16
0
4470
[offset 40]
0x82 (130)
1 to 4
6
- - - -
30006
uint
RWES
[sas;b]
[SAS.b]
Counter (1 to 8)
State Active Source B
Set what output state will
indicate on.
[high]
High (37)
[LoW]
Low (53)
High
4482
[offset 40]
0x82 (130)
1 to 4
0x0C (12)
- - - -
30012
uint
RWES
[LoAd]
[LoAd]
Counter (1 to 8)
Load Value
Set the counter's initial
value.
0 to 9,999
0
4484
[offset 40]
0x82 (130)
1 to 4
0x0D (13)
215
30013
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
