Watlow EZ-ZONE ® RME Module • 72 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[a;unt]
[A.unt] Math (1 to 8)
Altitude Units
If Math function is set for
Pressure to Altitude units,
set units of measure for
conversion.
[`Hft] Kilofeet (1671)
[``ft] Feet (1674)
Kilofeet 2240
[offset 70]
0x7D (125)
1 to 8
0x1F (31)
- - - - 25031 uuint
RWES
[`FiL]
[ FiL] Math (1 to 8)
Filter
Filtering smooths out the
output signal of this func-
tion block. Increase the
time to increase filtering.
0.0 to 60.0 seconds 0.0 2234
[offset 70]
0x7D (125)
1 to 8
0x1C (28)
- - - - 25028 float
RWES
[`SoF]
[`Set]
Special Output Function Menu
[``Fn]
[ Fn] Special Output (1 to 4)
Function
Set the function to match
the device it will operate.
[`oFF] Off (62)
[`SE;C] Sequencer (1507)
[`uA;C] Motorized Valve
(1508)
[`Co;C] Compressor Control
(1506)
Off 6636
[offset 80]
0x87 (135)
1 to 4
9
181 35009 uint
RWES
[sfn;A]
[SFn.A] Special Output (1 to 4)
Source Function A
Set the type of function
that will be used for this
source.
[nonE] None (61)
[``ai] Analog Input (142)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop
(73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``pu] Process Value (241)
[sof;1] Special Function
Output 1 (1532)
[`uAr] Variable (245)
None 6620
[offset 80]
0x87 (135)
1 to 4
1
182 35001 uint
RWES
[`si;A]
[ Si.A] Special Output (1 to 4)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 6624
[offset 80]
0x87 (135)
1 to 4
3
183 35003 uint
RWES
[`s2;A]
[ SZ.A] Special Output (1 to 4)
Source Zone A
Set the zone of the function
selected above.
0 to 16 0 6628
[offset 80]
0x87 (135)
1 to 4
5
- - - - 35005 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
