Watlow EZ-ZONE ® RME Module • 44 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[otpt]
[`Set]
Output Menu
[``Fn]
[ Fn] Output Digital (1 to 4, 7 to
10, 13 to 16, 19 to 22)
Function
Select what function will
drive this output.
[`oFF] Off (62)
[``ai] Analog Input (142)
[ALM] Alarm (6)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out
A (233)
[Ent;b] Profile Event Out
B (234)
[Ent;C] Profile Event Out
C (235)
[Ent;d] Profile Event Out
D (236)
[Ent;E] Profile Event Out
E (247)
[Ent;F] Profile Event Out
F (248)
[Ent;g] Profile Event Out
G (249)
[Ent;h] Profile Event Out
H (250)
[`FUn] Function Key
(1001)
[`lgC] Logic (239)
[`lnr] Linearization (238)
[mat] Math (240)
[``pu] Process Value (241)
[SoF;1] Special Function
Output 1 (1532)
[SoF;2] Special Function
Output 2 (1533)
[SoF;3] Special Function
Output 3 (1534)
[SoF;4] Special Function
Output 4 (1535)
[tMr] Timer (244)
[`uAr] Variable (245)
- - - - 368
[offset 30] 0x6A (106)
1 to (24)
5
- - - - 6005 uint
RWES
[``Fi]
[ Fi] Output Digital (1 to 4, 7 to
10, 13 to 16, 19 to 22)
Function Instance
Set the instance of the
function selected above.
1 to 24 1 370
[offset 30] 0x6A (106)
1 to (24)
6
- - - - 6006 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
