Watlow EZ-ZONE
®
RME Module
•
67
•
Chapter 4 Setup Page
RME Module
•
Setup Page
Dis-
play
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[sfn;h]
[SFn.h]
Logic (1 to 8)
Source Function H
Set the type of function
that will be used for this
source.
[none]
None (61)
[ALM]
Alarm (6)
[`CPE]
Compare (230)
[`Ctr]
Counter (231)
[`dio]
Digital I/O (1142)
[Ent;A]
Profile Event Out
A (233)
[Ent;b]
Profile Event Out
B (234)
[Ent;C]
Profile Event Out
C (235)
[Ent;d]
Profile Event Out
D (236)
[Ent;E]
Profile Event Out
E (247)
[Ent;F]
Profile Event Out
F (248)
[Ent;g]
Profile Event Out
G (249)
[Ent;h]
Profile Event Out
H (250)
[`FUn]
Function Key
(1001)
[lim]
Limit (126)
[`lgC]
Logic (239)
[SoF;1]
Special Function
Output 1 (1532)
[SoF;2]
Special Function
Output 2 (1533)
[SoF;3]
Special Function
Output 3 (1534)
[SoF;4]
Special Function
Output 4 (1535)
[tMr]
Timer (244)
[`uAr]
Variable (245)
None
3034
[offset 80]
0x7F (127)
1 to 8
8
- - - -
27008
uint
RWES
[`si;h]
[ Si.h]
Logic (1 to 8)
Source Instance H
Set the instance of the
function selected above.
1 to 250
1
3050
[offset 80]
0x7F (127)
1 to 8
0x10 (16)
- - - -
27016
uint
RWES
[`s2;h]
[ SZ.h]
Logic (1 to 8)
Source Zone H
Set the zone of the function
selected above.
0 to 16
0
3066
[offset 80]
0x7F (127)
1 to 8
0x18 (24)
- - - -
27024
uint
RWES
[`Er;h]
[ Er.h]
Logic (1 to 8)
Error Handling
Use to select the output
value and error output
state of this function if it
receives an error signal
from one or more sources
and it cannot determine
the output value.
[``t;g]
True Good (1476)
[``t;b]
True Bad (1477)
[``F;g]
False Good (1478)
[``F;b]
False Bad (1479)
False Bad 3088
[offset 80]
0x7F (127)
1 to 8
0x23 (35)
- - - -
27035
uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E:
EEPROM
S:
User Set
