Watlow EZ-ZONE ® RME Module • 57 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`LEu]
[ LEv] Timer (1 to 8)
Active Level
Set which output state will
indicate on.
[high] High (37)
[LoW] Low (53)
High 4966
[offset 50]
0x83 (131)
1 to 8
0x0E (14)
- - - - 31014 uint
RWES
[`Ctr]
[`Set]
Counter Menu
[``fn]
[ dir] Counter (1 to 8)
Function
Set whether the counter
increments or decrements
the count value. Decre-
menting 0 returns 9,999.
Incrementing 9,999 returns
0.
[``UP] Up (1456)
[``dn] Down (1457)
Up 4476
[offset 40]
0x82 (130)
1 to 4
9
- - - - 30009 uint
RWES
[sfn;;A]
[SFn.A] Counter (1 to 8)
Source Function A
Set the type of function
that will be used for this
source which is the counter
clock signal.
[none] None (61)
[ALM] Alarm (6)
[`C;Pr] Cool Power, Control
Loop (161)
[`CPE] Compare (230)
[`Ctr] Counter (231)
[`dio] Digital I/O (1142)
[Ent;A] Profile Event Out
A (233)
[Ent;b] Profile Event Out
B (234)
[Ent;C] Profile Event Out
C (235)
[Ent;d] Profile Event Out
D (236)
[Ent;E] Profile Event Out
E (247)
[Ent;F] Profile Event Out
F (248)
[Ent;g] Profile Event Out
G (249)
[Ent;h] Profile Event Out
H (250)
[`FUn] Function Key
(1001)
[`lgC] Logic (239)
[tMr] Timer (244)
[`uAr] Variable (245)
None 4460
[offset 40]
0x82 (130)
1 to 4
1
- - - - 30001 uint
RWES
[`si;A]
[ Si.A] Counter (1 to 8)
Source Instance A
Set the instance of the
function selected above.
1 to 250 1 4464
[offset 40]
0x82 (130)
1 to 8
3
- - - - 30003 uint
RWES
[`s2;A]
[ SZ.A] Counter (1 to 8)
Source Zone A
Set the zone of the function
selected above.
0 to 16 0 4468
[offset 40]
0x82 (130)
1 to 4
5
- - - - 30005 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
