Watlow EZ-ZONE ® RME Module • 46 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[``Fn]
[ Fn] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Function **
Set the type of function
that will drive this output.
[`oFF] Off (62)
[``Ai] Analog Input (142)
[CUrr] Current (22)
[`C;Pr] Cool Power, Control
Loop (161)
[`h;Pr] Heat Power, Control
Loop (160)
[PWr] Power, Control Loop
(73)
[`Lnr] Linearization (238)
[MAt] Math (240)
[``Pu] Process Value (241)
[`SP;C] Set Point Closed,
Control Loop (242)
[`SP;o] Set Point Open,
Control Loop (243)
[SoF;1] Special Function
Output 1 (1532)
[SoF;2] Special Function
Output 2 (1533)
[SoF;3] Special Function
Output 3 (1534)
[SoF;4] Special Function
Output 4 (1535)
[`uAr] Variable (245)
Off 6992
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
2
- - - - 18002 uint
RWES
[``Fi]
[ Fi] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Function Instance **
Set the instance of the
function selected above.
1 to 16 1 6996
[offset 60]
0x76 (118)
1-3, 7-9,
13-15, 19-
21
4
- - - - 18004 uint
RWES
[`S2;A]
[ ZS.A] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Source Zone A **
Set the zone of the function
selected above.
0 to 16 0 7026
[offset 60]
0x76 (118)
1-3, 7-9,
13-15, 19-
21
0x13 (19)
- - - - 18019 uint
RWES
[`S;Lo]
[ S.Lo] Output Process (1 to 3, 7 to
9, 13 to 15, 19 to 21)
Scale Low **
Set the scale low for pro-
cess output in electrical
units. This value, in volts
or milliamps, will cor-
respond to 0% PID power
output or range low value.
-100.0 to 100.0 0.00 7006
[offset 60] 0x76 (118)
1-3, 7-9,
13-15, 19-
21
9
- - - - 18009 float
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
