Watlow EZ-ZONE ® RME Module • 49 • Chapter 4 Setup Page
RME Module • Setup Page
Dis-
play
Parameter Name
Description
Range Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`A;Si]
[ A.Si] Alarm (1 to 8)
Silencing
Turn alarm silencing on to
allow the user to disable
this alarm.
[`oFF] Off (62)
[``on] On (63)
Off 1450
[offset 60]
0x6D (109)
1 to 8
6
11 9006 uint
RWES
[A;dSP]
[A.dSP] Alarm (1 to 8)
Display
Display an alarm message
when an alarm is active.
[`oFF] Off (62)
[``on] On (63)
On 1470
[offset 60]
0x6D (109)
1 to 8
0x10 (16)
12 9016 uint
RWES
[`A;dL]
[ A.dL] Alarm (1 to 8)
Delay
Set the span of time that
the alarm will be delayed
after the process value ex-
ceeds the alarm set point.
0 to 9,999 seconds 0 1480
[offset 60]
0x6D (109)
1 to 8
0x15 (21)
13 9021 uint
RWES
[a;Clr]
[A.CLr] Alarm (1 to 8)
Alarm Clear Request **
Write to this register to
clear an alarm
0 - - - - 1490
[offset 60] 0x6D
(109)
1 to 8
0xD (13)
14 9013 uint
W
[A;sir]
[A.Sir] Alarm (1 to 8)
Alarm Silence Request
**
Write to this register to
silence an alarm
0 - - - - 1492
[offset 60] 0x6D
(109)
1 to 8
0xE (14)
15 9014 uint
W
[`a;st]
[ A.St] Alarm (1 to 8)
Alarm State **
Current state of alarm
Startup (88)
None (61)
Blocked (12)
Alarm low (8)
Alarm high (7)
Error (28) - - - - 1456
[offset 60] 0x6D
(109)
1 to 8
9
- - - - 9009 uint
R
[CUrr]
[`Set]
Current Menu
[`C;Sd]
[ C.Sd] Current (1 to 4)
Sides
Use Current Sides to select
which side of the current to
monitor.
[`oFF] Off (62)
[high] High (37)
[low] Low (53)
[both] Both (13)
off 1088
[offset 50]
0x73 (115)
1 to 4
5
145 15005 uint
RWES
[`C;Ur]
[ C.Ur] Current (1 to 4)
Read Enable
Use Current Read Enable
to display solid-state relay
(SSR) failure and heater
failure messages on the
RUI (remote user inter-
face).
[``no] No (59)
[`yes] Yes (106)
no 1086
[offset 50]
0x73 (115)
1 to 4
4
146 15004 uint
RWES
[`C;dt]
[ C.dt] Current (1 to 4)
Detection Threshold
Current Detection Thresh-
old is for factory use only.
3 to 59 9 1102
[offset 50]
0x73 (115)
1 to 4
0xC (12)
147 15012 uint
RWES
Note:
Some values will be rounded off to fit in the four-character display . Full values can be read
with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EEPROM
S: User Set
