Watlow EZ-ZONE
®
RME Module
•
31
•
Chapter 3 Operations Page
RME Module
•
Operations Page
Display
Parameter Name
Description
Range
Default
Modbus
Relative
Address
CIP
Class
Instance
Attribute
hex (dec)
Profibus
Index
Param-
eter
ID
Data
Type
&
Read/
Write
[`dio]
[oPEr]
Digital Input / Output Menu
[`do;S]
[ do.S]
Digital Output (1 to 24)
Output State
View the state of this
output.
[`off]
Off (62)
[``on]
On (63)
- - - -
372
[off 30]
0x6A (106)
1 to 18 (24)
7
28
6007
uint
R
[`di;S]
[ di.S]
Digital Input (1 to 24)
Input State
View this event input
state.
[`off]
Off (62)
[``on]
On (63)
- - - -
380
[off 30]
0x6A (106)
1 to 18 (24)
0xB (11)
- - - -
6011
uint
R
No Dis-
play
Digital Input (1 to 24)
Source Error
View reported cause for
input malfunction.
None (61)
Open (65)
Shorted (127)
Measurement error (140)
Bad calibration data (139)
Ambient error (9)
RTD error (14)
Fail (32)
Math error (1423)
Not sourced (246)
Stale (1617)
- - - -
388
[offset 30]
0x6A
(106)
1 to 18
(24)
0x0F (15)
- - - -
6015
uint
R
[`ACt]
[oPEr]
Action Menu
[`Ei;S]
[ Ei.S]
Action (1 to 8)
Event Status
View this input state.
[`off]
Off (62)
[``on]
On (63)
- - - -
1288
[off 20]
0x6E (110)
1 to 8
5
74
10005
uint
R
[ALM]
[oPEr]
Alarm Menu
[`A;Lo]
[ A.Lo]
Alarm (1 to 8)
Low Set Point
If Alarm Type (Setup
Page, Alarm Menu) is
set to:
process - set the process
value that will trigger a
low alarm.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
32.0°F
or units
0.0°C
1442
[off 60]
0x6D
(109)
1 to 8
2
0
9002
float
RWES
[`A;hi]
[ A.hi]
Alarm (1 to 8)
High Set Point
If Alarm Type (Setup
Page, Alarm Menu) is
set to:
process - set the process
value that will trigger a
high alarm.
-1,999.000 to 9,999.000°F
or units
-1,128.000 to 5,537.000°C
300.0°F
or units
150.0°C
1440
[off 60]
0x6D
(109)
1 to 8
1
1
9001
float
RWES
[a;Clr]
[A.CLr]
Alarm (1 to 8)
Alarm Clear Request
Write to this register to
clear an alarm
0
None
1464
[offset 60]
0x6D
(109)
1 to 8
0xD (13)
14
9013
uint
W
Note:
Some values will be rounded off to fit in the four-character display . Full values can be
read with other interfaces .
Note:
If there is only one instance of a menu, no submenus will appear .
** These parameters/prompts are available in these menus with firmware revisions 6 .0 and
above .
R: Read
W: Write
E: EE-
PROM
S: User
Set
